Differnece in VHO and vortec max


  • Please log in to reply
19 replies to this topic

#1 HAZMAT

HAZMAT

    Littering and.. Littering and.. smokin the reefer

  • Member
  • PipPipPip
  • 732 posts
  • Gender:Male
  • Location:West Hills, CA
  • Owns:SS
  • Color:Victory Red
  • Year:2006

Posted 08 March 2007 - 02:50 PM

I think i remember reading a post on the differnece between a VHO and vortec max but couldn't find it does anyone know where the post is or what the difference between the 2 are?
  • 0
Posted Image

mods-custom Vortech s trim s/c , custom tune, magna flow dual in/out, exhaust, trangsgo hd2, vette servos, 160 t-stat,

#2 Bad Bowtie

Bad Bowtie

    *Elite SS Member*

  • Member
  • PipPipPipPip
  • 2,899 posts
  • Gender:Male
  • Location:Texas
  • Owns:Fan
  • Color:Graystone
  • Drivetrain:2WD

Posted 08 March 2007 - 04:05 PM

This should be interesting! LOL!! 2004-2005 = VHO, 2006-07 = Vortec Maxx. I'll let everyone else here explain the mechanical differences...
  • 0
Posted Image

http://www.cardomain.com/id/2004VHO

GMC. The Strength of Experience.

#3 Nxtnlne

Nxtnlne

    [email protected]

  • Member
  • PipPipPip
  • 957 posts
  • Gender:Male
  • Location:SoCal
  • Owns:V-Max
  • Color:Dark Blue Met
  • Year:2006
  • Drivetrain:4WD

Posted 08 March 2007 - 07:56 PM

My V-max package came with a 4l70e, 14 bolt with 4:10 gears and 17' wheels also the V-Max package is availible in 4wd and 2wd 4 door and extra cab...The VHO (b4v) came with 20' wheels and the 4l65e only in 2 wheels drive extended cab apickups with a 10 bolt and 3:73 gears. I could be wrong though Love that sig by the way!!!! little sideways.....

Pulled this artivcle from the net...............
The Vortec High Output (also know as the VHO by some enthusiasts) was first introduced in 2004 to a limited market (mainly consisting of Texas and several surrounding areas). The VHO package (under option code B4V) included several options previously not found on the standard 1500 model, most notably the LQ9 6.0 liter V-8 engine (the same used for the Silverado SS and the Cadillac Escalade). The LQ9 motor was rated at 345 hp at 5200 rpm and 380 lb.-ft. of torque at 4000 rpm, which was the same specifications shared in the SS models. The package also included one style of the newly introduced GM 20 inch wheels installed from the factory. The B4V package could only be ordered on an extended cab, light duty, 2 wheel drive Silverado or Sierra. This marked the first time the LQ9 engine was available for a two wheel drive application. For the 2006 model year the Vortec Max package replaced the VHO with an array of similar features and new badges. It was also made available for crew cab models (in addition to the extended cab) and customers were able to purchase these trucks outside of the original market of the VHO. The Vortec Max Performance package boasts an industry leading 10,000 pounds towing capacity.


The Vortec HO 6000 or VortecMAX, technically the LQ9, is a special high-output version of the Vortec 6000 V8 truck engine originally designed for Cadillac. This engine was introduced in other truck lines as VortecMAX for 2006. It features high-compression (10:1) flat-top pistons for an extra 10 hp and 10 ftlbf, bringing output to 345 hp (257 kW) and 380 ftlbf (515 Nm). LQ9s are built only in Romulus, Michigan.

LQ9 Applications:

* 2002-2005 Cadillac Escalade
* 2002-2005 Cadillac Escalade EXT
* 2003-2005 Cadillac Escalade ESV
* 2003-2005 Chevrolet Silverado SS
* 2004-2005 Chevrolet Silverado and GMC Sierra Vortec HO Edition Only [Badging on truck]
* 2006-2007 Chevrolet Silverado and GMC Sierra VortecMAX Option
  • 0
Posted Image

2006 Silverado VortecMax:4x4
LT3..14 bolt with 4:10's..4L70e..Elec. ride control shocks..
GMPP CAI, Magnaflow dumped, 20' D'vinci Pasha's on General Grabber UHPs
2005 Yukon XL
SLT 4:10's


#4 Champion210

Champion210

    I Fish Because The Voices In My Head Tell Me To.

  • Member
  • PipPipPipPip
  • 1,064 posts
  • Gender:Male
  • Location:South Central California
  • Owns:VHO
  • Color:Black
  • Year:2005
  • Drivetrain:2WD

Posted 09 March 2007 - 06:57 PM

The below is for my 2005 VHO, and all other 2005 VHO's I believe

SILVERADO PERFORMANCE EDITION, option code B4V
includes (LQ9) Engine, Vortec high-output 6000 V8, (M32) Transmission, 4-speed automatic, heavy-duty, (GT4) Rear axle, 3.73 ratio, (Z60) Suspension Package, High-Performance, (G80) Differential, locking, heavy-duty, rear, (NW7) Traction assist system, electronic, (KC4) Cooling, engine oil, (KNP) Cooling, external transmission oil cooler, (Z82) Trailering equipment, heavy-duty, (UK3) Sound system feature, steering wheel mounted radio controls, (QR9) Wheels, 4 - 20" x 8.5", cast aluminum, chromed, 5-spoke, (QSS) Tires, P275/55R20, touring, blackwall, (ZAN) Tire, spare P265/70R17, blackwall and 17" Wheel, steel, spare (Requires CC15753 Models

An updated 4L60-E, the 4L65-E (RPO M32), was phased in around the 2003 model year when coupled behind the 6.0 Vortec. Five-pinion planetaries, along with a modified drum/input shaft assembly, were improved to withstand up to 380 ftlbf (515 Nm) of torque.
  • 0


Posted Image


#5 Nxtnlne

Nxtnlne

    [email protected]

  • Member
  • PipPipPip
  • 957 posts
  • Gender:Male
  • Location:SoCal
  • Owns:V-Max
  • Color:Dark Blue Met
  • Year:2006
  • Drivetrain:4WD

Posted 09 March 2007 - 07:21 PM

The below is for my 2005 VHO, and all other 2005 VHO's I believe

SILVERADO PERFORMANCE EDITION, option code B4V
includes (LQ9) Engine, Vortec high-output 6000 V8, (M32) Transmission, 4-speed automatic, heavy-duty, (GT4) Rear axle, 3.73 ratio, (Z60) Suspension Package, High-Performance, (G80) Differential, locking, heavy-duty, rear, (NW7) Traction assist system, electronic, (KC4) Cooling, engine oil, (KNP) Cooling, external transmission oil cooler, (Z82) Trailering equipment, heavy-duty, (UK3) Sound system feature, steering wheel mounted radio controls, (QR9) Wheels, 4 - 20" x 8.5", cast aluminum, chromed, 5-spoke, (QSS) Tires, P275/55R20, touring, blackwall, (ZAN) Tire, spare P265/70R17, blackwall and 17" Wheel, steel, spare (Requires CC15753 Models

An updated 4L60-E, the 4L65-E (RPO M32), was phased in around the 2003 model year when coupled behind the 6.0 Vortec. Five-pinion planetaries, along with a modified drum/input shaft assembly, were improved to withstand up to 380 ftlbf (515 Nm) of torque.


VORTEC MAX PACKAGE: includes (LQ9) Engine, Vortec high-output 6000 V8 with "VortecMax" engine cover, (M70) Transmission, 4-speed automatic, super duty, (GT5) Rear axle, 4.10 ratio (includes (GT4) Rear axle,(G80) Differential, locking, heavy-duty, rear, (ZX3) Suspension Package, Ride-Control, (KC4) Cooling, external engine oil cooler, (KNP) Cooling, external transmission oil cooler, auxiliary, and (Z82) Trailering equipment, heavy-duty (NHT)
  • 0
Posted Image

2006 Silverado VortecMax:4x4
LT3..14 bolt with 4:10's..4L70e..Elec. ride control shocks..
GMPP CAI, Magnaflow dumped, 20' D'vinci Pasha's on General Grabber UHPs
2005 Yukon XL
SLT 4:10's


#6 BRUTONMOTORSPORTZ

BRUTONMOTORSPORTZ

    Senior SS Member

  • Member
  • PipPip
  • 196 posts
  • Location:TEMPLE, TX
  • Color:Dark Grey Met
  • Year:2004

Posted 10 March 2007 - 03:18 PM

2004 VHOs did not have traction control as standard equipment. 04 VHOs had rear disc and the same rear diff as other Silverados for that year. 05 VHO went to 9 1/2 rear and drums.
  • 0
2004 Chevrolet 1500 Ext. Cab SWB LS 6.0L Vortec HO (LQ9) VHO
Magnacharger Radix Supercharger
B&B side exit exhaust
SS Gauge cluster
Escalade door handles on outside with Denali handles inside. Denali dash bezel.
ISS Headrest covers
ISS Spoiler

2005 Chevrolet Z71 4X4 Suburban
Stock baby hauling grocery getter.

1998 Camaro Z28 6speed. Sold
1999 Camaro SS 6speed. Sold
2002 Camaro Z28 1SC 6speed. Sold
2002 Camaro SS Auto. Sold.

#7 cerbomark

cerbomark

    Senior SS Member

  • Member
  • PipPip
  • 471 posts
  • Location:northern New Jersey
  • Color:Summit White
  • Year:2007
  • Drivetrain:4WD

Posted 21 March 2007 - 08:24 PM

VORTEC MAX PACKAGE: includes (LQ9) Engine, Vortec high-output 6000 V8 with "VortecMax" engine cover, (M70) Transmission, 4-speed automatic, super duty, (GT5) Rear axle, 4.10 ratio (includes (GT4) Rear axle,(G80) Differential, locking, heavy-duty, rear, (ZX3) Suspension Package, Ride-Control, (KC4) Cooling, external engine oil cooler, (KNP) Cooling, external transmission oil cooler, auxiliary, and (Z82) Trailering equipment, heavy-duty (NHT)

That says it best , and you can get this with 17in wheels as well as 20 s.at least in 07 NBS)

Edited by cerbomark, 21 March 2007 - 08:25 PM.

  • 0
2004 SS SOLD /2007 V max- Silverado, 6.0, 4:10 s, PCM tune SOLD/ 2009 GMC Sierra 5.3/6spd crew cab

Sig removed for size restriction violation.

Mark, Northern New Jersey/Upstate New York

#8 shakesvho

shakesvho

    Supercharged

  • Member
  • PipPipPipPip
  • 1,236 posts
  • Gender:Male
  • Location:Cajun Country
  • Owns:VHO
  • Color:Silver Birch Metallic
  • Year:2005
  • Drivetrain:2WD

Posted 21 March 2007 - 09:48 PM

The VHO (b4v) came with 20' wheels and the 4l65e only in 2 wheels drive extended cab apickups with a 10 bolt and 3:73 gears. I could be wrong though Love that sig by the


05 - 14 bolt 9.5" ring gear differential
  • 0

DD: 2008 TB LS/LT Nose Job

Garage Queen: 2005 Silverado VHO |MP122HH |GT7 |LT | Built 4l65e/2800 | List Goes On |


#9 Fat Nick

Fat Nick

    SS Member

  • Member
  • Pip
  • 25 posts
  • Location:Williamsburg, VA
  • Owns:V-Max
  • Color:Black
  • Year:2006
  • Drivetrain:2WD

Posted 23 March 2007 - 03:05 PM

Not all V-Max's are 4.10 trucks, my 06 has 3.73's.
  • 0
2006 Black/Tan Silverado V-Max: DRL delete, snorkel removal, hacked off catback
294/352
14.8@92

2005 Black/Red GTO M6: Comp Cam 236/238 .601/.605 112lsa, SLP 1 3/4" LT's w/cats, Flowmaster 40's, Ported LS2 intake manifold/tb, ASP UD, Lingenfelter CAI, Tuned by Williams Performance of Mooresville, NC
427/390
12.3@117

#10 Nxtnlne

Nxtnlne

    [email protected]

  • Member
  • PipPipPip
  • 957 posts
  • Gender:Male
  • Location:SoCal
  • Owns:V-Max
  • Color:Dark Blue Met
  • Year:2006
  • Drivetrain:4WD

Posted 24 March 2007 - 12:19 AM

VORTEC MAX PACKAGE: includes (LQ9) Engine, Vortec high-output 6000 V8 with "VortecMax" engine cover, (M70) Transmission, 4-speed automatic, super duty, (GT5) Rear axle, 4.10 ratio (includes (GT4) Rear axle,(G80) Differential, locking, heavy-duty, rear, (ZX3) Suspension Package, Ride-Control, (KC4) Cooling, external engine oil cooler, (KNP) Cooling, external transmission oil cooler, auxiliary, and (Z82) Trailering equipment, heavy-duty (NHT)



Not all V-Max's are 4.10 trucks, my 06 has 3.73's.


You are right.......Hence the (GT5) Rear axle, 4.10 ratio (includes (GT4) Rear axle......

GT5 = 4:10, GT4 = 3.73
  • 0
Posted Image

2006 Silverado VortecMax:4x4
LT3..14 bolt with 4:10's..4L70e..Elec. ride control shocks..
GMPP CAI, Magnaflow dumped, 20' D'vinci Pasha's on General Grabber UHPs
2005 Yukon XL
SLT 4:10's


#11 Nxtnlne

Nxtnlne

    [email protected]

  • Member
  • PipPipPip
  • 957 posts
  • Gender:Male
  • Location:SoCal
  • Owns:V-Max
  • Color:Dark Blue Met
  • Year:2006
  • Drivetrain:4WD

Posted 24 March 2007 - 12:25 AM

05 - 14 bolt 9.5" ring gear differential


:thumbs:
  • 0
Posted Image

2006 Silverado VortecMax:4x4
LT3..14 bolt with 4:10's..4L70e..Elec. ride control shocks..
GMPP CAI, Magnaflow dumped, 20' D'vinci Pasha's on General Grabber UHPs
2005 Yukon XL
SLT 4:10's


#12 Blazing60

Blazing60

    SS Newbie

  • Newbie
  • 3 posts
  • Gender:Male
  • Location:Florida
  • Owns:SS
  • Color:Silverstone
  • Year:2006
  • Drivetrain:2WD

Posted 26 March 2007 - 08:26 PM

:thumbs:

I am going to buy a 2007 new style 1500 with the vortec 6.0L Variable Vaule Timing v8 SFI it says it is rated at 367hp and 375 torque. My question is, is this engine any different from the one that comes in the silverado ss or is it more powerfull or is it the same exact engine. Also is it High output and what is the difference between SFI and MFI. I would like a SS but I need the crew cab what do you guys think?
  • 0

#13 NoRiceInside

NoRiceInside

    SS Newbie

  • Member
  • 9 posts
  • Owns:V-Max
  • Color:Black
  • Year:2006
  • Drivetrain:AWD

Posted 16 May 2007 - 05:29 PM

(ZX3) Suspension Package, Ride-Control


what 'ride control' ?
  • 0

#14 4ws f 7

4ws f 7

    SS Newbie

  • Member
  • 7 posts
  • Color:Black
  • Year:2005
  • Drivetrain:4WD

Posted 02 June 2007 - 04:43 PM

(ZX3) Suspension Package, Ride-Control


what 'ride control' ?



If I had my camera here I would take a picture of the button on dash near the pass. air bag off key switch looks like a bumpy road on switch, which is to switch from normal to harder
dampening on shocks. Note: this is on my 4 wheel steering truck which ZX3 came standard.
  • 0

#15 WinSomeLoseSome

WinSomeLoseSome

    Senior SS Member

  • Member
  • PipPip
  • 168 posts
  • Gender:Male
  • Location:odessa,tx
  • Owns:V-Max
  • Color:Dark Grey Met
  • Year:2006
  • Drivetrain:2WD

Posted 13 June 2007 - 02:41 PM

I think i remember reading a post on the differnece between a VHO and vortec max but couldn't find it does anyone know where the post is or what the difference between the 2 are?



from what i heard the heads are diff v-max has more compression
  • 0
